Wattsan 1610 LT (2025)
CNC wood cutting laser, LT series.
| Working area | 1600 x 1000 mm |
|---|---|
| Laser tube power | 100-120 W |
| Max. speed | 500 mm |
| Dimensions | 2200 x 1500 x 660 mm + 343 mm (if on wheels) |
| Net weight | 252 kg |
| Package size | 2290 x 1580 x 840 mm |
| Package weight | 442 kg |
Product Features
The 1610 series handles full-size sheets of plywood, MDF, and acrylic — up to 1600 x 1000 mm in a single setup. This eliminates the need to reposition material between cuts, reducing production time and improving alignment accuracy for large batch work.
From the 1610 series upward, the machine body is 2.7 mm thick or more. This increased thickness reduces vibration during high-speed engraving, extends the machine's service life, and ensures problem-free operation in continuous production environments without frequent recalibration.
The 1610 series includes the Wattsan FOX (Fire Overwatch Expert) system as standard. FOX monitors the working area continuously and triggers an immediate loud alarm upon detecting ignition or smoke, minimizing downtime and protecting both the machine and the workshop from fire damage.
The enclosed motion module and enhanced airflow system improve ventilation and reduce dust buildup in the gantry mechanics. A built-in ammeter provides precise real-time power readings, allowing the operator to verify actual laser output and adjust settings for consistent cut quality.
The LT series adds a chain-driven asynchronous motor lift table that handles materials up to 80 kg without slipping or misalignment. The table lowers up to 160 mm, allowing work with thick stone slabs, foam blocks, or mounted rotary devices for engraving cylindrical objects.
