Wattsan
Wattsan 1610 ST (2025)
Cena bez PVN
CNC wood cutting machine, ST series.
| Darba lauks | 1600 x 1000 mm |
|---|---|
| Lāzera caurules jauda | 100-120 W |
| Maks. ātrums | 500 mm |
| Izmēri | 2200 x 1500 x 660 mm + 343 mm (if on wheels) |
| Neto svars | 400 kg |
| Iepakojuma izmērs | 2290 x 1580 x 840 mm |
| Iepakojuma svars | 442 kg |
Product Features
The 1610 series handles full-size sheets of plywood, MDF, and acrylic — up to 1600 x 1000 mm in a single setup. This eliminates the need to reposition material between cuts, reducing production time and improving alignment accuracy for large batch work.
From the 1610 series upward, the machine body is 2.7 mm thick or more. This increased thickness reduces vibration during high-speed engraving, extends the machine's service life, and ensures problem-free operation in continuous production environments without frequent recalibration.
The 1610 series includes the Wattsan FOX (Fire Overwatch Expert) system as standard. FOX monitors the working area continuously and triggers an immediate loud alarm upon detecting ignition or smoke, minimizing downtime and protecting both the machine and the workshop from fire damage.
The enclosed motion module and enhanced airflow system improve ventilation and reduce dust buildup in the gantry mechanics. A built-in ammeter provides precise real-time power readings, allowing the operator to verify actual laser output and adjust settings for consistent cut quality.
Product showcase
